What You’ll Learn in This Tutorial

By the end of this tutorial, you’ll learn how to:

• Scrape tabular weather data from JMA’s website using requests library
• Parse and give structure to the raw data with Beautiful Soup library
• Clean and save the data as a CSV file

If you prefer to skip the explanations and jump straight to the implementation, you can download this blog post as a Jupyter notebook.

Here are the list of things you’ll need to run the code.

Prerequisites

• A copy of this blog as a Jupyter notebook
• ‘SampleData_JMA’ subfolder for saving the CSV output
• Python libraries
  • requests
  • bs4
  • pandas

Jargon

Data scraping: Using code to extract information from a web page or a source that’s primarily designed for human viewing. In this blog post, we’ll be pulling data from an HTML table on the JMA site.

Data parsing: Converting raw or unstructured text into something structured and easy to work with. For example, turning HTML table rows into a tidy pandas DataFrame.

Step 1: Designate the URL with the Weather Data

First, we’ll need the URL of the JMA webpage that contains the specific data we want to scrape. If you’d like to know the actual data scraping and parsing methods and do not care much for finding a specific JMA station, skip ahead to step 2.

For those interested in finding your own JMA weather station, you can navigate the records of past weather data from here. Refer to Figure 1 below to:

1. Narrow down on the JMA weather site by designating the prefecture (red box)
2. Pinpoint the observation site within the prefecture (orange box, activated once you designate the prefecture)
3. Choose the year, month and day for the desired data (green box)
4. Select the type of weather data to access (blue box)

You may need a combination of Google maps, a translation app and trial and error to navigate to your desired URL. You’ll also notice that the column headers in the tables differ depending on the type of data you’ve selected from the blue box in Figure 1.

For the remainder of this blog post, we’ll work with the 10-minute interval weather records. You can select the “１０分ごとの値” option located on the left column within the blue box, second from the bottom for a JMA observation site and date of your preference. I’ve provided a default test URL below, which accesses 10-minute interval weather records from the Tokyo site on March 9, 2024.

# URL containing 10-minute interval weather data from Tokyo site on March 9, 2024
# Can be replaced with 10-minute data from any 's1' type observation site
testURL = 'https://www.data.jma.go.jp/stats/etrn/view/10min_s1.php?prec_no=44&block_no=47662&year=2024&month=3&day=9&view='

Accessing this URL, we find the tabular weather data which we will be scraping:

Step 2: Data Scraping with the requests Library

Next, we’d like to scrape all the HTML from the webpage. We’ll need to import the requests library to do the scraping.

# Library required for data scraping
import requests

The requests.get() function inside this library can send an HTTP GET request to the designated URL:

# HTTP GET request to testURL
# Execute care to avoid running multiple requests in a very short period of time
step2_resp = requests.get(testURL)

This returns a Response object, a class defined by the requests library, that stores the server’s reply when accessing the designated URL. The Response object has many attributes, including its content.

print("Returned object type:\n\t", type(step2_resp))

# Properties of Response object
step2_prop = step2_resp.__dict__.keys()
print("\nProperties and attributes in object:")
for prop_now in step2_prop:
    print('\t', prop_now)

Returned object type:
     <class 'requests.models.Response'>

Properties and attributes in object:
     _content
     _content_consumed
     _next
     status_code
     headers
     raw
     url
     encoding
     history
     reason
     cookies
     elapsed
     request
     connection

Some of the other Response object attributes are useful for other applications, such as error handling. For now, we’ll ignore these use cases and parse the HTML content using Beautiful Soup.

Step 3: Initial HTML Parsing with Beautiful Soup

With the response in hand, we can now parse the raw HTML. Import the BeautifulSoup() function from bs4:

# Import the BeautifulSoup function from bs4 library
from bs4 import BeautifulSoup

Much like how humans understand a sequence of words only when the sequence follows a set of known grammatical rules, a computer program needs to know what to expect to make sense of the raw data. In other words, when a program “reads” HTML, it needs an HTML parser to understand and process it.

We’ll use Python’s built-in HTML parser, html.parser to make sense of the contents of the Response object from step 2. This will return a BeautifulSoup object.

# HTML parser to make sense of the Response object
step3_soup = BeautifulSoup(step2_resp.content, "html.parser")
print("Returned object type:\n\t", type(step3_soup))

Returned object type:
     <class 'bs4.BeautifulSoup'>

After parsing HTML with BeautifulSoup, we can safely navigate the contents. Namely, HTML consists of tags that define specific sections within the content. Most elements follow the pattern:

<tag_name> ...content... </tag_name>

Tags are often nested in a form of hierarchy. For example, every webpage can be broadly divided into two major sections, each with subsections:

• <head> contains metadata, scripts, page title
• <body> contains the visible content, including the tabular data

Let us print just the <head> section to see what structured HTML looks like:

print(step3_soup.head.prettify())

<head>
 <meta charset="utf-8"/>
 <title>
  気象庁｜過去の気象データ検索
 </title>
 <meta content="気象庁 Japan Meteorological Agency" name="Author"/>
 <meta content="気象庁 Japan Meteorological Agency" name="keywords"/>
 <meta content="気象庁｜過去の気象データ検索" name="description"/>
 <meta content="text/css" http-equiv="Content-Style-Type"/>
 <meta content="text/javascript" http-equiv="Content-Script-Type"/>
 <link href="/com/css/define.css" media="all" rel="stylesheet" type="text/css"/>
 <link href="../../css/default.css" media="all" rel="stylesheet" type="text/css"/>
 <script language="JavaScript" src="/com/js/jquery.js" type="text/JavaScript">
 </script>
 <script language="JavaScript" src="../js/jquery.tablefix.js" type="text/JavaScript">
 </script>
 <style media="all" type="text/css">
  <!-- @import url(/com/default.css); -->
 </style>
 <link href="../../data/css/kako.css" media="all" rel="stylesheet" type="text/css"/>
 <link href="../../data/css/print.css" media="print" rel="stylesheet" type="text/css"/>
</head>

The nested hierarchy structure can be easily spotted in the first lines:

<head>
  ...
  <title>
  気象庁｜過去の気象データ検索
  </title>
  ...
</head>

In a similar manner, the tabular data to extract is contained within <body> ...tabular data... </body>.

Step 4: Navigate the HTML and Extract the Desired Table

Unfortunately, the HTML body contains much more than the tabular data. If you are curious as to just how much content is inside the HTML body, try running the following code on your own:

print(step3_soup.body)

You can scroll through the whole HTML and manually search out the tags containing the tabular data. However, I will show you a slightly more sophisticated 🧐 search method, which takes advantage of the following:

• Target data is likely within <table> ... </table> tags
• Target data contains '00:10' as a data element as seen in Figure 2

The BeautifulSoup.find_all() method can search for all <table> tags, and pinpoint the table containing '00:10' as a string.

# Find all the <table> tags
step4_tables = step3_soup.body.find_all('table')

print("Total number of <table> tags:\t", len(step4_tables), '\n')

# Search for '00:10' string in the table
for table in step4_tables:
    print(table.attrs) # Print attributes of the table

    # If the '00:10' string is inside this table
    if table.find_all(string='00:10') != []:
        print('\tFound the target table:')
        # If the table contains the '00:10' string, print out the first five rows
        table_contents = table.find_all('tr')
        for i in range(3):
            print('\t\t', table_contents[i])

Total number of <table> tags:    6

{'style': 'float:left'}
{'style': 'margin-left: auto'}
{'style': 'float:left;margin-top: 25px'}
{'style': 'margin-left: auto;margin-top: 25px'}
{'id': 'tablefix1', 'class': ['data2_s']}
    Found the target table:
         <tr class="mtx"><th rowspan="2" scope="col">時分</th><th colspan="2" scope="colgroup">気圧(hPa)</th><th rowspan="2" scope="col">降水量<br/>(mm)</th><th rowspan="2" scope="col">気温<br/>(℃)</th><th rowspan="2" scope="col">相対湿度<br/>(％)</th><th colspan="4" scope="colgroup">風向・風速(m/s)</th><th rowspan="2" scope="col">日照<br/>時間<br/>(分)</th></tr>
         <tr class="mtx" scope="col"><th scope="col">現地</th><th scope="col">海面</th><th scope="col">平均</th><th scope="col">風向</th><th scope="col">最大瞬間</th><th scope="col">風向</th></tr>
         <tr class="mtx" style="text-align:right;"><td style="white-space:nowrap">00:10</td><td class="data_0_0">1003.3</td><td class="data_0_0">1006.3</td><td class="data_0_0">--</td><td class="data_0_0">3.3</td><td class="data_0_0">96</td><td class="data_0_0">1.1</td><td class="data_0_0" style="text-align:center">西</td><td class="data_0_0">1.7</td><td class="data_0_0" style="text-align:center">西南西</td><td class="data_0_0"></td></tr>
{'style': 'margin-left:auto;margin-right:0px'}

By selectively searching for the '00:10' string nested inside <table> tags, we have quickly isolated the meteorological data buried inside the long HTML <body>. The contents within the first few table rows (as specificed by <tr> tags) confirm that the desired data is, indeed, in this table.

The printed out table attributes indicate that the desired table has:

• ID of tablefix1
• class of data2_s

We can now select the one desired table by specifying either #id or .class in the soup.select() method:

# Select the target table with either code below
step4_targetTable = step3_soup.select('table.data2_s')
#step4_targetTable = step3_soup.select('table#tablefix1') # Alternative method

print("Number of tables selected:\t", len(step4_targetTable))

Number of tables selected:   1

However, for the tabular data to be useful in data analysis projects, HTML format is not ideal. We will work through the table row-by-row, cell-by-cell to migrate data from the HTML format to a pandas DataFrame.

To process the table row-by-row, re-write the soup.select() function to find the <tr>, or table row tag elements, within <table class=data2_s>:

# Select all rows within the target table
step4_tableRows = step3_soup.select('table.data2_s tr')

This provides us with an object with 146 separate table rows. Inspecting the first few confirms we’ve successfully isolated the data we need.

print("Number of rows in table:\t", len(step4_tableRows))

# Print out the first couple table rows
for i in range(3):
    print('\t', step4_tableRows[i])

Number of rows in table:     146
     <tr class="mtx"><th rowspan="2" scope="col">時分</th><th colspan="2" scope="colgroup">気圧(hPa)</th><th rowspan="2" scope="col">降水量<br/>(mm)</th><th rowspan="2" scope="col">気温<br/>(℃)</th><th rowspan="2" scope="col">相対湿度<br/>(％)</th><th colspan="4" scope="colgroup">風向・風速(m/s)</th><th rowspan="2" scope="col">日照<br/>時間<br/>(分)</th></tr>
     <tr class="mtx" scope="col"><th scope="col">現地</th><th scope="col">海面</th><th scope="col">平均</th><th scope="col">風向</th><th scope="col">最大瞬間</th><th scope="col">風向</th></tr>
     <tr class="mtx" style="text-align:right;"><td style="white-space:nowrap">00:10</td><td class="data_0_0">1003.3</td><td class="data_0_0">1006.3</td><td class="data_0_0">--</td><td class="data_0_0">3.3</td><td class="data_0_0">96</td><td class="data_0_0">1.1</td><td class="data_0_0" style="text-align:center">西</td><td class="data_0_0">1.7</td><td class="data_0_0" style="text-align:center">西南西</td><td class="data_0_0"></td></tr>

Note that the first two rows in the table are column headers. The actual data starts on row 3. Additionally, the wind direction data is recorded as Japanese kanji characters. We’d like to convert these into English in a pandas DataFrame with the next step.

Step 5: Create a DataFrame with the Fully Parsed Data Using for Loops

From the isolated table rows, we extract the weather data and place them into a structured pandas DataFrame using a for loop to work through each row.

First, import the pandas library.

import pandas as pd

Then, create an empty DataFrame. I’ve provided the English translation of the column headers below:

# The Tokyo observation site (type s1) has 11 columns of data
headers_s1 = (['time',
               'local atmospheric pressure (hPa)',
               'sea level pressure (hPa)',
               'precipitation (mm)',
               'temperature (℃)',
               'relative humidity',
               'average wind speed (m/s)',
               'average wind direction',
               'max wind speed (m/s)',
               'max wind direction',
               'sunshine (minutes)'])

# If you are using a 'a1' type observation site, use the headers below
headers_a1 = (['time',
               'precipitation (mm)',
               'temperature (℃)',
               'relative humidity',
               'average wind speed (m/s)',
               'average wind direction',
               'max wind speed (m/s)',
               'max wind direction',
               'sunshine (minutes)'])

# Specify the header you'll be using
headers_now = headers_s1 # Change to headers_a1 if using 'a1' type observation site

# Empty dataframe to fill with data
step5_df = pd.DataFrame(columns=headers_now)

Referring back to the sample table rows from the previous step, a few things stand out:

1. The first two table rows contain no data, only headers
2. Every data row begins with a <td> or table data tag containing the time in 'HH:MM' format
3. All remaining meteorological values appear inside <td class="data_0_0"> elements.

We can use these patterns to guide our parsing when working row-by-row in the for loop. Start by skipping the header information.

# Iterate through each row in the table
for rowNow in step4_tableRows:

  # Search for the data_0_0 class (actual weather data)
  list_data = rowNow.select('td.data_0_0')

  if len(list_data) == 0:
    # There is no data in this row (ie. column headers), so skip
    print("Skipping row: ", rowNow)
    continue

Skipping row:  <tr class="mtx"><th rowspan="2" scope="col">時分</th><th colspan="2" scope="colgroup">気圧(hPa)</th><th rowspan="2" scope="col">降水量<br/>(mm)</th><th rowspan="2" scope="col">気温<br/>(℃)</th><th rowspan="2" scope="col">相対湿度<br/>(％)</th><th colspan="4" scope="colgroup">風向・風速(m/s)</th><th rowspan="2" scope="col">日照<br/>時間<br/>(分)</th></tr>
Skipping row:  <tr class="mtx" scope="col"><th scope="col">現地</th><th scope="col">海面</th><th scope="col">平均</th><th scope="col">風向</th><th scope="col">最大瞬間</th><th scope="col">風向</th></tr>

# Iterate through each row in the table
rowCount = 0
for rowNow in step4_tableRows:

  # Search for the data_0_0 class that contains the weather data
  list_data = rowNow.select('.data_0_0')

  if len(list_data) == 0:
    # There is no data in this row (ie. it is a column headers), so skip
    #print("Skipping row: ", rowNow)
    continue

  else:
    # Extract time
    time1 = rowNow.select_one('td') # Select just the first <td> tag element
    time2 = time1.text.strip()      # Remove the tags with .text(). Remove extra spaces with strip()
    #print(time2)

    # Assign the time to the first column in the DataFrame
    step5_df.loc[rowCount, headers_now[0]] = time2

    # Increment rowCount
    rowCount = rowCount + 1

print("First few lines:")
print(step5_df['time'].head())
print("\nLast few lines:")
print(step5_df['time'].tail())

First few lines:
0    00:10
1    00:20
2    00:30
3    00:40
4    00:50
Name: time, dtype: object

Last few lines:
139    23:20
140    23:30
141    23:40
142    23:50
143    24:00
Name: time, dtype: object

def ConvertKanji2NESW(kanji_windDir):
    """Function to convert the wind direction from kanji to English
    AUTHOR:     Mai Tanaka (www.DataDrivenMai.com)
    DATE:       2026-03-31
    REQUIRES:   kanji_windDir = Full kanji indicating wind direction (eg. '北東')
    RETURNS:    english_windDir = Wind direction in English in N/E/S/W notation (eg. 'NE')
    """
    # Start with an empty string
    english_windDir = ''

    # Handle the special case: 静穏 (tranquil or no wind)
    if kanji_windDir == '静穏':
        english_windDir = 'tranquil'
        return english_windDir

    # Kanji to character (NESW) conversion, character-by-character
    for kanji_char in kanji_windDir:
        if kanji_char == '北':
            english_windDir = english_windDir + 'N'
        if kanji_char == '東':
            english_windDir = english_windDir + 'E'
        if kanji_char == '南':
            english_windDir = english_windDir + 'S'
        if kanji_char == '西':
            english_windDir = english_windDir + 'W'

    # Return English wind direction
    return english_windDir

# Iterate through each row in the table
rowCount = 0
for rowNow in step4_tableRows:

  # Search for the data_0_0 class
  list_data = rowNow.select('.data_0_0')

  if len(list_data) == 0:
    # There is no data in this row, so skip
    #print("Skipping row: ", rowNow)
    continue

  else:
    # Extract time
    time1 = rowNow.select_one('td') # Select just the first <td> tag element
    time2 = time1.text.strip()      # Remove the tags with .text(). Remove extra spaces with strip()
    #print(time2)

    # Assign the time to the DataFrame
    step5_df.loc[rowCount, headers_now[0]] = time2

    # Work through each data element to extract meteorological data
    columnCount = 1
    for dataNow in list_data:
      # Extract just the data (remove tags and spaces)
      justData = dataNow.text.strip()

      # If the data type is wind direction, convert from Kanji to alphabet
      if "wind direction" in headers_now[columnCount]:
        justData = ConvertKanji2NESW(justData)

      # Save the data into the appropriate location and increment columnCount
      step5_df.loc[rowCount, headers_now[columnCount]] = justData
      columnCount = columnCount + 1

    # Increment the rowCount
    rowCount = rowCount + 1

step5_df.head()

Step 6: Save DataFrame as a CSV File

In the final step, we save the fully populated and cleaned DataFrame as a CSV file. We can use pandas’ built-in pandas.to_csv() method to write the data out. Just specify the desired file path (and make sure the directory exists in your local environment), disable the index column, and choose an appropriate text encoding (UTF-8 is a safe default).

# Specify a strong filename in a directory that exists
fileName = 'test_JMADataScraping_step6.csv'
dirName = 'SampleData_JMA/'
savefileName = dirName + fileName
step5_df.to_csv(savefileName, index=False, encoding='utf-8')

This saves a CSV file with the scraped and parsed weather data that you can access any time.
